Rigid Plate Deflection at D
scene 3 of 5
The figure shows a rigid triangular plate B C D which is pinned at C, supported at B by a horizontal rod of length 1200 millimeters and supported at D by a vertical post of height 600 millimeters. The clearance between the post and the plate is 1.5 millimeters. The post is fixed to the ground at E and the rod is fixed to a wall at A. The plate has dimensions 600 millimeters along C D and 480 millimeters along B C. A load P directed vertically downwards acts on the plate and this causes the plate to rotate about C and makes contact with the post at D.

If the strain in the post is –1,800 με, how much has the post been compressed?
