The box beam is constructed from two 18-mm thick plywood sheets and two 75 mm by 100 mm wood flanges.
The wood flanges are connected to the plywood webs with
12-mm-diameter steel bolts spaced at 300-mm intervals along the 6-m beam span.
Determine the average shear stress in each bolt and the bearing stress between the bolts and the plywood web.
