Transformation Equations in Terms of Double Angles
scene 11 of 12

These equations are known as the stress transformation equations for plane stress.

Derivation of stress transform equations

Double angle trigonometric identities may be used to simplify the transformation equations.

Derivation of stress transform equations

Using the double angle trigonometric functions, the equations for plane stress may be written in terms of 2θ:

Derivation of stress transform equations
