Diagram shows an aluminum shaft A B with a support at A, marked 1 of length 4,000 millimeters and a brass shaft B C with a support at C, marked 2 of length 3,000 millimeters with a flange in between at B. The shafts are centered on the x axis. A torque T is applied at B.

A composite shaft consists of a hollow steel (G=76 GPa) shaft (1) connected to a solid bronze (G=38 GPa) shaft (2) at flange B. The outside diameter of shaft (1) is 80 mm and the inside diameter is 65 mm. The outside diameter of shaft (2) is 80 mm.

The allowable shear stresses for the steel and bronze materials are 90 MPa and 50 MPa, respectively.

Determine:

• The maximum torque T that can be applied to flange B.

• The stresses τ1 and τ2 developed in the steel and bronze shafts.

• The angle of rotation of flange B.
