Equilibrium
scene 5 of 15
Diagram shows an aluminum shaft A B with a support at A of length 1,500 millimeters and a brass shaft B C with a support at C of length 1,000 millimeters with a flange in between at B. The shafts are centered on the x axis. A torque T is applied at B.

Draw a FBD around flange B.
